Gate Valve

A Gate Valve is a linear-motion shut-off valve designed to start or stop the flow of fluid by raising or lowering a heavy-duty gate or wedge. Operating perpendicular to the fluid flow, it provides a straight-through, unobstructed flow path with minimal pressure drop when fully open.

Body & Bonnet Material

Cast/Ductile Iron, Carbon Steel, Stainless Steel (CF8/CF8M)

Gate/Disc Type

Solid, Knife, Split Wedge, Flexible Wedge

Size

1/2" Up To 40" (DN15 - DN1000)

Connection

Flange, Threaded, Butt Weld, Socket Weld, Wafer/Lug

Pressure Rating

ASME Class 150-600, EN Class PN16 - PN40, JIS 10K-30K

Stem Design

Non-Rising Stem (NRS), Rising Stem (OS&Y)
